PoE Splitter 12V 2.5A Output 30W DC-DC Converter for Network Equipment

Designed for anyone looking to power non-PoE devices like IP cameras, access control systems, or media players using existing PoE infrastructure.

• High-Power 12V PoE Splitter for Non-PoE Devices: Convert IEEE 802.3af/at PoE (Power over Ethernet) into 12V DC output for devices like IP Cameras, Media Players, Access Control Systems, and Network Devices. Perfect for powering non-PoE 12V devices using your existing PoE infrastructure.
• 30W High Power Output: Supports up to 30W of continuous power, ideal for devices that demand more energy, such as high-power Wi-Fi access points, video conferencing systems, or advanced outdoor security cameras. Equipped with a 5.5mm x 2.5mm DC barrel jack for easy connection.
• Seamless Compatibility: Works with any IEEE 802.3af/at PoE switch or injector, including popular brands like Cisco, Netgear, and Ubiquiti. Supports 10/100/1000Mbps Gigabit speeds, ensuring fast data transmission alongside power delivery.
• Extended Power and Data Reach: With support for 42-57V PoE input, the splitter can extend both DC power and Gigabit data over a distance of up to 328 feet (100 meters), making it perfect for long-distance installations.
• Built-In Safety Features: Includes overcurrent and short circuit protection to safeguard your devices, ensuring stable and reliable performance even in challenging environments.
• Designed for Durability: Operates efficiently in extreme conditions, with an operating temperature range of -30°C to +75°C, making it suitable for both indoor and outdoor applications.

Product Features

• Input: 42V~57V
• Output: 12V/2.5A Barrel jack
• Safety: Over current and short circuit protection
• Power Pins:1/2(+),3/6(-) or 4/5(+),7/8(-)
• Data Pins: 1/2,3/6,4/5,7/8
• Gigabit Data speed: 10/100/1000Mbps
• Operating Temperature: -30°C～+75°C

What makes us different?

• High Power Output:

  • Supports 802.3af/at (PoE+) standards.
  • It delivers up to 30W per port, with approximately 25.5W available for the powered device.
  • Perfect for demanding devices such as advanced PTZ IP cameras, high-power Wi-Fi access points, and video conferencing systems.

• Gigabit Data Speeds:

  • Ensures smooth data transmission with support for 10/100/1000 Mbps speeds.
  • Ideal for high-performance networks requiring fast and reliable connectivity.

• Built-in Safety and Compatibility:

  • Features overcurrent and short-circuit protection to safeguard your devices.
  • Compatible with all IEEE 802.3af/at PoE injectors and switches, such as Cisco, Netgear, and Ubiquiti.

Looking for Other Options?

• Need 5V Output Instead? Check out our RAK9168 5V Version, which provides 5V/6A output (30W) via a USB Type-C connector, suitable for powering devices like Raspberry Pi, small electronics, and IoT applications.

• Need a PoE Injector? If you don’t already have a PoE switch or injector, pair the RAK9168 with our 1000M PoE Injector, designed to deliver 48V DC, 0.5A output.

Why Choose RAK9168?

The RAK9168 stands out for its 30W power capability, Gigabit-ready speeds, and compatibility with a wide range of non-PoE devices. Whether upgrading a network, powering high-demand devices, or simplifying installations, this splitter offers a reliable and efficient solution tailored to your needs.

Package Inclusions

• 1x RAK9168/12V PoE splitter
• 1x Barrel jack cable (29cm length)
• 1x Ethernet cable (27cm length)

Documentation

• PoE Splitter RAK9168 Datasheet
