Outdoor Gateway Enclosure
Prefer another courier for your delivery? Contact us for special shipping arrangements.
Buy from your local authorized seller
The Outdoor Gateway Enclosure is available through our trusted distributors. Choose your region below to visit their website:
Industrial Die-Cast Aluminum Design
Designed to withstand the toughest of environments, this enclosure is made of Industrial Die-Cast Aluminum. It is rated IP67/NEMA-6, making it completely protected from dust ingress and submergible up to 1m in water.
Complete documentation of this product can be found on our website documentation page.
Thermal Characteristics
- Enclosure seal operating temperature range: -60°C to 230°C
- Heat Trap: +6.5°C under full sun exposure (~ 100,000 Lux)
- Temperature raise using a 5-10W heat source: +5.5°C
Ports
- Ports For RAKBox-GW-1
- 5x N-Type Antenna connectors
- 1x Ethernet cable gland
- 1x Reserved port
- For RAKBox-GW-0
- 2x N-Type Antenna connectors
Supported Products
- WisGate Edge Max (RAK7249)
- RAK831 Concentrator Boards
- RAK7243C Pilot Gateway
Packaging
- Product Dimensions: 450mm x 300mm x 150mm
- Product Weight: 3400g
-
Inclusions:
- Enclosure together with connectors
- The full assembly kit is included
