10x WisGate Edge Prime
RAK7240 + Free Logo A
Prefer another courier for your delivery? Contact us for special shipping arrangements.
Product Description
WisGate Edge Prime (RAK7240) is an ideal product for large scale LPWAN deployment where cost-effectiveness and performance are crucial. Its wide range of customization options allows for flexibility when deploying a solution, you can even choose to print your own logo in its enclosure for a minimal fee!
Before, logo customization for this product is only available for a minimum order quantity (MOQ) of 100 units. We received a considerable amount of inquiries asking if logo customization is possible for smaller quantities. Because of this, we reduced the MOQ to only 10 units!
RAK7240 gives you a solid out-of-the-box experience for quick IoT deployment. Since its software and UI sit on top of OpenWRT, it is perfect for custom application development via open SDK.
Using RAK7240 for roll-out projects is beneficial since it can cater up to 128 nodes (license included) and it operates in license-free sub-gigahertz radio frequency bands like 433 MHz, 868 MHz (Europe), 915 MHz (Australia and North America), and 923 MHz (Asia).
Hardware Features
- IP65 industrial-grade enclosure with cable glands
- PoE + Surge Protection
- Dual LoRa® Concentrators for up to 16 channels
- Backhaul: Wi-Fi, LTE, and Ethernet
- GPS
- SD card slot
Software Features
- Built-in LoRa® Server (up to 128 LoRa® nodes license included; higher tiers require a fee)
- OpenVPN
- Software and UI sit on top of OpenWRT
- LoRaWAN® 1.0.2
- LoRa® Frame filtering (node whitelisting)
- MQTT v3.1 Bridging with TLS encryption
- Buffering of LoRa® frames in case of NS outage (no data loss)
Package Inclusions
- 8 Channels without 4G (RAK7240-0X)
- 1x 8-channel device
- 1x LoRa Antenna
- 1x GPS Antenna
- 1x 2.4G Wi-Fi Antenna
- 1x PoE Injector
- 1x Mounting Kit
- 1x Manual
- 8 Channels with 4G (RAK7240-0X-14X )
- 1x 8-channel device with LTE module
- 1x LoRa Antenna
- 2x LTE Antenna
- 1x GPS Antenna
- 1x 2.4G Wi-Fi Antenna
- 1x PoE Injector
- 1x Mounting Kit
- 1x Manual
- 16 Channels without 4G (RAK7240-1X )
- 1x 16-channel device
- 2x LoRa Antenna
- 1x GPS Antenna
- 1x 2.4G Wi-Fi Antenna
- 1x PoE Injector
- 1x Mounting Kit
- 1x Manual
- 16 Channels with 4G (RAK7240-1X-14X)
- 1x 16-channel device with LTE module
- 2x LoRa Antenna
- 1x LTE Antenna
- 1x GPS Antenna
- 1x 2.4G Wi-Fi Antenna
- 1x PoE Injector
- 1x Mounting Kit
- 1x Manual
