RAK3272-SiP Breakout Board
Prefer another courier for your delivery? Contact us for special shipping arrangements.
RAK3272-SiP Breakout Board is an evaluation board for the new RAK3172-SiP System in a Package LPWAN module. It makes it easy to evaluate the power of the RAK3172-SiP module with access to all pin's of the SIP module. All pins are accessible on 6 rows of Pin headers with a standard pitch of 2.54mm.
The RAK3172-SiP is a low-power long range transceiver system in a package (SiP) that is based on STM32WLE5 chip. It provides an easy to use, small size, low-power solution for long range wireless data applications. This module complies with Class A, B & C of LoRaWAN 1.0.4 specifications. It can easily connect to different LoRaWAN server platforms like TheThingsNetwork (TTN), Chirpstack, Actility, etc. It also supports LoRa Point-to-Point (P2P) communication mode which helps you in implementing your own customized long-range LoRa network quickly.
You can configure the mode and operation of the module using AT commands via a UART interface. RAK3172 also offers low power features which is very suitable for battery-powered applications. It is RUI3 compatible which allows you to create custom firmware using RUI3 APIs.
Note:
- The RAK3272-SiP version does support up to 22dBm TX power.
-
The RAK3272LP-SiP version is the low power version and supports only up to 15dBm TX power.
| SKU | Model# | Description | Frequency |
|---|---|---|---|
| 315042 | RAK3272-SiP | STM32WLE5 SiP Module with breakout board | 8XXMHz for EU868/IN865/RU864 |
| 316040 | RAK3272-SiP | STM32WLE5 SiP Module with breakout board | 9XXMHz for US915/AU915/KR920/AS923 |
| 315048 | RAK3272LP-SiP | Low Power Version STM32WLE5 SiP Module with breakout board | 8XXMHz for EU868/IN865/RU864 |
| 316050 | RAK3272LP-SiP | Low Power Version STM32WLE5 SiP Module with breakout board | 9XXMHz for US915/AU915/KR920/AS923 |
Features
- Based on RAK3172-SiP
- RUI3 API compatible
- LoRaWAN 1.0.4 specification compliant
- Supported bands: IN865, EU868, AU915, US915, KR920, RU864, and AS923
- LoRaWAN Activation by OTAA/ABP
- LoRa Point-to-Point (P2P) communication
- Easy to use AT Command Set via UART interface
- Long-range - up to 15 km with optimized antenna
- Ultra-Low Power Consumption of 1.69 μA in sleep mode
- Supply Voltage: 2.0 V ~ 3.6 V
- Temperature Range: -40° C ~ 85° C
- Module size: 25.4 x 32.3 mm
Package Inclusion
- 1pcs RAK3272-SiP Breakout Board
- 1pcs 2dBi SubG Antenna(Antenna for LoRa®)
- 18pcs Dupont lines
Documentation
