Outdoor Enclosure for WisGate Developer Gateway
Prefer another courier for your delivery? Contact us for special shipping arrangements.
Note: The RAK7244, RAK7244C, RAK7244P not included in the Outdoor Enclosure Kit.
The provided PoE Injector and Splitter are not Gigabit (1000Mbps) Ethernet capable. They are 10/100Mbps devices, working only with 10/100Mbps ports on routers and switches.
In case you want to use a 1000Mbps switch or router to provision your hotspot, you need to source a Gigabit Ethernet capable PoE injector and splitter.
Product Description
The Kit includes all necessary parts to make your WisGate Developer Gateway or RAK Hotspot V2 Outdoor.
Product Inclusions
- Outdoor Enclosure Kit for WisGate Developer D4 (RAK7244)
-
Outdoor Enclosure Kit
- PoE splitter Type-C USB (in 48 V; out 5 V/2.4 A)
- PoE injector (in 100-240 V; out 48 V/0.5 A)
- Power cord for the PoE Injector
- Zip tie, PVC tape, and waterproof tape
- Antenna cable type RG316, with N-type to RP-SMA male connectors for LoRa antenna
- Antenna cable type RG316, with N-type to SMA male connectors for GPS antenna
- GPS Antenna with mounting brackets
- Outdoor Enclosure Kit for WisGate Developer D4+ (RAK7244 D4+)
- Outdoor Enclosure Kit
- PoE splitter Type-C USB (in 48 V; out 5 V/2.4 A)
- PoE injector (in 100-240 V; out 48 V/0.5 A)
- Power cord for the PoE Injector
- Zip tie, PVC tape, and waterproof tape
- Antenna cable type RG316, with N-type to RP-SMA male connectors for LoRa antenna
- Antenna cable type RG1.32, with N-type to RP-SMA male connectors for LTE antenna x2.
- Antenna cable type RG316, with N-type to SMA male connectors for GPS antenna
- GPS Antenna with mounting brackets
- LTE antenna x2
- Outdoor Enclosure Kit for WisGate Developer D4P (RAK7244 D4P)
- Outdoor Enclosure Kit
- PoE injector (in 100-240 V; out 48 V/0.5 A)
- Power cord for the PoE Injector
- Zip tie, PVC tape, and waterproof tape
- Antenna cable type RG316, with N-type to RP-SMA male connectors for LoRa antenna
- Antenna cable type RG316, with N-type to SMA male connectors for GPS antenna
- GPS Antenna with mounting brackets
