2dBi SubG Antenna

Product Description

This antenna for LoRa® frequencies has a gain of 2dBi and is compatible with RAK's wide-range of LPWAN modules and boards. You can use TTN's guide to know what frequency you need based on your country/region or use the Regional Parameters Documentation provided by LoRa Alliance®.

Key Features

• Band: support the Global Multiple Bands
• Connector Type: RP-SMA Male
• Gain: 2.0 dBi
• Polarization: Linear
• Impedance: 50 Ohm
• V.S.W.R: 1:1.5
• Material
• Radiator: Copper
• Body: TPE
• Hinge & Holder: PA+ABS
• Operation Temperature: - 40 ºC ~ + 80 ºC
• Storage Temperature: - 40 ºC ~ + 95 ºC

Packaging

• Antenna Dimensions: 109mm x 10mm
• Antenna Weight: Approximately 0.2kg

Documentation

• Datasheet RP-SMA Antenna 860Mhz - 868Mhz
• Datasheet RP-SMA Antenna 915Mhz - 930Mhz
